Features
- Compact diameter
- Excellent to work with due to the use of a special AL/PT-foil
- Flexible due to the special wire construction
- Good shielding due to the overall and individual wire pair shielding
- Very good pricing
Technical Data
| PVC jacket, diameter | 9.5 mm |
| AWG | 26 |
| No. of inner conductors | 8 x 2 x 0.14mm² |
| Copper strand per conductor | 18 x 0.10 mm |
| Conductor insulation | PE 1.05 mm |
| Shielding | AL/PT-foil + drain wire 7 x 0.15 mm tin plated copper |
| Shielding factor | 100% |
| Temperature range | min.-20 °C |
| Temperature range | max. 70 °C |
Electrical Data
| Capac. cond./cond. per 1 m | 65 pF |
| Capac. cond./shield. per 1 m | 130 pF |
| Cond. resistance per 1 m | 125 mΩ |
| Shield. resistance per 1 m | 110 mΩ |
