APPLICATION & ASSEMBLY INSTRUCTION_POWERLINK
Features
- Lockable 3 pole equipment(AC) connectors
- Thicker silver plated brass and beryllium brozne contacts supply excellent contact and conduction properties
- Replaceable color ring on connector indicates cable of different equipment or length, easy for works
- Dust-proof design of the bushing makes the additional protection
- Raw material according with UL-V0 for safe use
- 2 pieces strain-relief clamps are provided for different cable diameter
- Patent-protected
Technical Data
| Housing | PA6 30%GF |
| Contacts | Beryllium Bronze |
| Contacts plating | Silver |
| Number of contacts | 3 |
| Rated current per contact | 20 A rms |
| Rate voltage | 250 V ac |
| Fammability | UL V-0 |
