Features
- Low delay skew due to the special structure
- Highly flexible due to special wire stranded technology and PVC jacket
- Great durability, outdoor temperature resistant, easy to reel
- Large wire cross-section AWG23 for long distance use up to 100m
- Foam-skin PE insulation and shielded in pairs with AL-foil
Technical Data
| Jacket, diameter | PVC 8.0 mm |
| AWG | 23 |
| No. of inner conductors | 4 x 2 x 0.26 mm² |
| Copper strand per conductor | 1 x 0.58 mm |
| Conductor insulation | Foam-skin PE |
| Shielding | Braided shielding with 128 x 0.12 mm + AL/PT-foil + drain wire 7 x 0.16 mm |
| Shielding factor | 100% |
| Temperature range | Min. -20 °C |
| Temperature range | Max. +75 °C |
| Packaging | 100/300 m roll |
Electrical Data
| Capac. cond./cond. per 1 m | 36.5 pF |
| Capac. cond./shield. per 1 m | 79 pF |
| Cond. resistance per 1 m | 68.8 mΩ |
| Shield. resistance per 1 m | 12 mΩ |
| color | Black |
| Length | 100m, 300m |
