EclProfile JrZIP is an IP rated zoomable ellipsoidal designed for exterior application. EclProfile JrZIP reaches an exceedingly high lumen output of nearly 6'000 lumens, and all in a compact size allowing for use on any outdoor show or for logo and texture projection over buildings. EclProfile JrZIP can use two different manual zoom lenses (optional) being 15° - 30° or 25° - 50° and it can be mounted at any distance from the projection surface.
EclProfile JrZIP is an IP rated zoomable ellipsoidal designed for exterior application. EclProfile JrZIP reaches an exceedingly high lumen output of nearly 6'000 lumens, and all in a compact size allowing for use on any outdoor show or for logo and texture projection over buildings. EclProfile JrZIP can use two different manual zoom lenses (optional) being 15° - 30° or 25° - 50° and it can be mounted at any distance from the projection surface.
Features:160W white LED engine with 3.000 K CT, delivering nearly 6'000 lumens
IP65 allowing for temporary outdoor installations and events
Optional optics available: 15° - 30° and 25° - 50°
- Source:160WWarm White LED
- Source CCT:(TU) 3.100 K - (DY) 5.500K
- Luminous flux:(TU - 50°) 5'274 lm - (TU - 25°) 5'770 lm; (TU - 30°) 4'200 lm - (TU - 15°) 5'012 lm - (DY - 50°) 5'390 lm - (DY - 25°) 4'911 lm; (DY - 30°) 3'844 lm - (DY - 15°) 4'450
- Lux:(TU - 50°) 2'040 lx - (TU - 25°) 5'160 lx; (TU - 30°) 3'710 lx - (TU - 15°) 12'900 lx - (DY - 50°) 1'750 lx - (DY - 25°) 4'530 lx; (DY - 30°) 3'000 lx - (DY - 15°) 11'200lx@3 m
- Lux:(TU - 50°) 734 lx - (TU - 25°) 1'857 lx; (TU - 30°) 1'336 lx - (TU - 15°) 4'644 - (DY - 50°) 630 lx - (DY - 25°) 1'630 lx; (DY - 30°) 1'080 lx - (DY - 15°) 4'032lx@5 m
- CRI:>90
- TLCI:91
- TM30 Rf:88
- TM30 Rg:97
- Source life expectancy:> 50.000 h
- Beam angle:(not included) manual zoom lens 15°-30° or (not included) manual zoom lens 25°-50°
- Lens diameter:87mm
- Lens type:high-quality glass lens optics
- Focus:manual
- Macros:several pre-built macros with adjustable speed
- Static mode:selection of static dimmer
- Manual mode:manual adjustment of dimmer and strobe
- Auto mode:built-in programs with execution speed adjustment
- Gobo size:(M size) 66 mm outer / 45 mm image / 1.1 mm thickness
- Supported Protocols:DMX512, W-DMX
- DMX channels:1 / 3ch
- RDM:for remote addressing and parameter configuration
- Display:Graphic User Interface
- Master/Slave:for synchronised operation of more units linked in a chain
- Other:16bit control of dimmer
- Dimmer:linear 0 - 100% electronic dimmer
- Dimmer curves:4selectable dimming modes available
- Strobe / shutter:1 - 30Hz, electronic
- Selectable PWM:600 to 25000 Hz (selectable steps)
- Firmware upgrade:via DMX with UPBOXPRO/UPBOX1 (not included)
- Power connection:Seetronic powerCON waterproof IN/OUT connectors
- Signal connection:Seetronic XLR 5p IN/OUT connectors
- Wireless Connection:integrated W-DMX receiver
- Mains power supply:100-240V - 50/60Hz
- Max power consumption (230V):136W
- Max power consumption (120V):138,6W
- Power factor:pF 0,98 @120 V - pF 0,97 @230 V
- IP rating:IP65 for temporary outdoor use
- Cooling:forced-air with low-noise fan
- Housing:Sturdy die-cast aluminium body
- Finish:black
- Operating temperature:Ta-20 to +45 °C (-4 to +113 °F)
- Dimensions (WxHxD):275x440x275mm
- Weight:7,9kg
- Suspension and fixing:bracket for hanging and positioning
- Hardware on-board:on board mechanics for rigging to the ceiling
- Compliance:CE, UKCA, RCM
