Prolights ECLFWHPIPVWBK

IP65 high quality Full White LED ellipsoidal Variable White, compatible with PRL and PRLZ lenses

QUOTE ONLY

Add to wishlist

View on Manufacturer Website

SKU: ECLFWHPIPVWBK

CATEGORY: Profile

BRAND: Prolights

DELIVERY For orders above AED 1,000

WARRANTY 2 years

SECURE PAYMENT Safe encrypted checkout

EXPERT SUPPORT Pre and post sale support

CONSULT AN EXPERT

Our team is ready to help you.

CONSULT AN EXPERT

Our team is ready to help you.

NEED A QUOTE?

We will provide custom pricing for your project.

REQUEST A QUOTE

ECLProfile FWHPIPVW is a true workhorse for white light applications. It features a 450 W LED engine delivering an impressive 16.600 lm output. The VariableWhite source provides excellent colour rendering for outstanding light quality and easy operation in broadcast studios, exhibitions/expos, and outdoor applications. Thanks to its IP65-rated housing, the fixture is suitable for outdoor use and challenging environmental conditions.

Designed for long throw distances and higher trim heights, the ECLProfile FWHPIPVW is an ideal replacement for traditional HPL 750 W and 2 kW tungsten ellipsoidals, excelling in large venues and outdoor productions.

ECLProfile FWHPIPVW delivers precise CCT reproduction with a user-friendly interface. The enhanced 2.4-inch display, paired with four RGB-backlit, push-to-select encoders, provides fast and intuitive control across multiple operating modes ensuring consistent and efficient operation for professionals, even in outdoor environments.

Despite its increased output and IP65 construction, the fixture maintains the compact footprint of its predecessor and remains compatible with industry-standard fixed and zoom optics, including PRL and PRLZ lenses. This enables seamless integration into existing inventories, making it a versatile and cost-effective solution for a wide range of indoor and outdoor lighting requirements.

450 W high-quality VariableWhite LED ellipsoidal, 16.600 lm

Linear white CCT from 2,700 K to 6,500 K

CRI and R9 up to 98

Silent operation, compatible with industry-standard accessories

IP65-rated for outdoor use

Features:
450 W high-quality VariableWhite LED ellipsoidal, 16.600 lm
Linear white CCT from 2,700 K to 6,500 K
CRI and R9 up to 98
Silent operation, compatible with industry-standard accessories
IP65-rated for outdoor use

LIGHT SOURCE

Source:

450
W

Variable White LED
Luminous flux:

(19°) 13'419 lm; (26°) 16'662 lm; (50°) 15'037 lm

@5.600 K
Lux:

(19°) 6'667 lx; (26°) 4'537 lx; (50°) 1'236
lx

@5 m 5.600 K
CRI:

up to 98
R9:

up to 98
TLCI:

up to 99
TM30 Rf:

96 @3200K; 96 @5600K
TM30 Rg:

103 @3200K; 102 @5600K
Source life expectancy:

> 50.000 h

OPTICS

Lens type:

high-quality glass lens optics
Additional optics:

optional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / 90° zoom 15°-30° / zoom 25°-50°
Focus:

manual
Other:

see available accessories

COLOUR SYSTEM

Colour mixing:

tunable white
CCT:

linear from 2.800K to 6.500K

DYNAMIC EFFECTS

Special features:

4 fan modes available and output management

GOBOS

Rotating gobos:

optional, see available accessories
Gobo size:

(B size) 86 mm outer / 64.5 mm image / 1.1 mm thickness

CONTROL

Supported Protocols:

DMX512, RDM, CRMX
DMX channels:

from 1 channel to 16
ch
RDM:

for remote addressing and parameter configuration
Display:

Graphic User Interface
Stand Alone:

4 pushable RGB backlit encoder
Master/Slave:

for synchronised operation of more units linked in a chain

ELECTRONICS

Dimmer:

linear 0 - 100% electronic dimmer
Dimmer curves:

4

selectable dimming modes available
Strobe / shutter:

1 - 25

Hz, electronic
Selectable PWM:

1282 to 20000 Hz (selectable steps)
Firmware upgrade:

via DMX with UPBOXPRO/UPBOX2 (not included) through dedicated software

CONNECTIONS

Power connection:

Seetronic powerCON TRUE IP65 IN/OUT
Signal connection:

IP65

Seetronic XLR 5p IN/OUT connectors
Wireless Connection:

integrated LumenRadio TimoTwo FX - CRMX, CRMX² (RX only) and W-DMX compatible, Bluetooth enabled

ELECTRICAL
