ControlGo is the ultimately flexible, multi functional lighting controller. This incredibly versatile, simple to use tool combines a fixture remote, RDM Tool, CRMX transmitter, DMX controller and DMX recorder into a single, portable and durable device.
Whether flashing out a film set, setting addresses on a tradeshow stand, or controlling battery uplighters, the ControlGO is THE device you need to get up and running quickly and easily.
Taking power from a host of options - NP-F or V-Lock batteries, DC 12-48V or USB-C - you won't find a place you cant find some power.
Featuring wired and CRMX wireless DMX & RDM, the ControlGO is compatible with up to 42 fixtures of any brand over 1 Universe. Its intuitive touchscreen interface, plus physical buttons and encoders, gives fast, easy and accurate access to its functions.
From Film sets to events … Lights, Control, Go!
ControlGo is the ultimately flexible, multi functional lighting controller. This incredibly versatile, simple to use tool combines a fixture remote, RDM Tool, CRMX transmitter, DMX controller and DMX recorder into a single, portable and durable device.
Whether flashing out a film set, setting addresses on a tradeshow stand, or controlling battery uplighters, the ControlGO is THE device you need to get up and running quickly and easily.
Taking power from a host of options - NP-F or V-Lock batteries, DC 12-48V or USB-C - you won't find a place you cant find some power.
Featuring wired and CRMX wireless DMX & RDM, the ControlGO is compatible with up to 42 fixtures of any brand over 1 Universe. Its intuitive touchscreen interface, plus physical buttons and encoders, gives fast, easy and accurate access to its functions.
From Film sets to events … Lights, Control, Go!
Features:One Universe DMX Controller , RDM controller, DMX recorder, Remote UI
5'' touchscreen with 4 RGB encoders and physical buttons for unprecedented user experience
Signal output through XLR, Wireless CRMX, and remote UI connector
Power sources: NP-F batteries (batteries not included), V-mount adapter plate, 48V DC remote UI, 12-48V DC input through SF6-M 4p, USB type-C 5-12V power input (power cable not included)
- On-board Screen:5”Full Color Touchscreen
- DMX Channels:512ch
- DMX out:1universe
- Supported Protocols:DMX512, RDM, CRMX + WDMX
- DMX channels:512ch
- RDM:for remote addressing and parameter configuration
- Display:5" Touch LCD
- Other:4 rotary push-encoders with RGB backlight
- Firmware upgrade:via DMX with UPBOXPRO/UPBOX1 (not included), via USB pen drive or onboard memory
- Battery:7.2VNP-F550/F570/F750/F770/F960/F970 type battery or V-Mounts (14.4V) via dedicated accessory
- Other:Batteries not included with the device.
- Signal connection:Seetronic XLR 5p OUT connector
- Wireless Connection:integrated LumenRadio TimoTwo FX - CRMX, CRMX² (RX only) and W-DMX compatible, Bluetooth enabled
- Data:1xUSB port
- Low Voltage DC connector:Weipu SA6(12-48V), Weipu SA12 (48V - RemoteConnector), USB type C PD3.0, Battery slots
- Low Voltage DC mains:12-48V via DC IN, 48V via Remote Connector, 5-9-12-20V via PD3.0 over USB-C, 7.2V via battery slots
- Max power consumption (230V):8W
- IP rating:IP20
- Cooling:passive, fan-free
- Housing:Sturdy polycarbonate body
- Finish:black
- Weight:0.6kg
- Hardware on-board:see available accessories
- Compliance:CE, RCM, FCC, cTUVus
