With the MAUI 44 G2 SUB W subwoofer, you can extend the cardioid characteristics of our professional column loudspeaker series into the bass range.
Well, what does that mean?Simply position the SUB next to your MAUI® 44 G2 (W) facing the rear direction, press the cardioid button and you will have a quieter and controlled Low-End on the back while still keeping the punch on the front. Low-End frequencies on the back of the system will be dampened by -15 dB. For extra Bass, keep the SUB in the same direction as your MAUI® 44 G2 (W) without pressing the cardioid button.
Setting up the SUB with your MAUI® 44 G2 (W) is straight forward and fast. Thanks to its automatic set-up detection system the SUB immediately switches to FOLLOWER mode as long as no column is attached.
Also recommendable is the protection cover and castor board to make transportation easy and keep the SUB as long as possible free of any touring-damage.
The MAUI® 44 G2 SUB W features the same design construction as the MAUI® 44 G2 (W) subwoofer and will be the perfect addition to get your Low-End in control.
- Powered 15" subwoofer with flow-optimised bass-reflex ports
- 15" custom-designed woofer with deep bass down to 37 Hz
- Preset-Switch for cardioid subwoofer configuration
- DynX® DSP technology for distortion-free sound at maximum volume
- Automatic set-up detection
- Rugged subwoofer housing made out of polyurea-coated birch plywood
- Shockproof front grille for ultimate speaker protection
- Two ergonomic handles covered in rubber for easy handling
- Attachment points for our MAUI® 44 G2 CB castor board
General
| Directivity | Cardioid |
|---|---|
| Peak output power | 1600 W |
| RMS output power | 800 W |
| Amp class | Class D |
| SysLink® | 0 |
| Max. SPL peak | 126 dB |
| Number of inputs | 2 |
| Input connector types | XLR 3-pole female |
| Number of outputs | 2 |
| Output connector types | XLR 3-pole male |
| Protection features | Direct current, Limiter, Overheating |
| Colour | White |
Bluetooth®
| Bluetooth® version | 4.0 |
|---|---|
| Features | Audio Streaming (A2DP), True Wireless Stereo |
| Supported audio codecs | AAC, aptX™, SBC |
| Receiver (client) | 0 |
| Transmitter (host) | 0 |
Inputs
| Number of line inputs | 2 |
|---|---|
| Line-In connector type | XLR 3-pole female |
Outputs
| Number of speaker outputs | 1 |
|---|---|
| Speaker output connection type | XLR 3-pole male |
| Number of line outputs | 2 |
| Line outputs connector type | XLR 3-pole male |
Signal processing
| Mixer | 0 |
|---|---|
| AD/DA converter bit depth | 24 Bit |
| AD/DA converter sampling rate | 48 kHz |
| Min. Signal-to-noise ratio (SNR) | 106 dB |
Bass driver
| Size | 15 " |
|---|---|
| Manufacturer | Custom Made |
| Magnet | Neodymium |
| Voice coil | 4 " |
Mains operation
| Operation voltage | 100 V AC - 240 V AC / 50 - 60 Hz |
|---|---|
| Power supply type | Switched-mode power supply (SMPS) |
Housing
| Design | Bass reflex |
|---|---|
| Number of handles | 2 |
| Cabinet material | Birch plywood |
| Material thickness | 18 mm |
| Front grille material | Aluminium |
Environmental
| Ambient temperature | 0 °C |
|---|---|
| Maximum air humidity (non-condensing) | 80 % |
Dimensions & weight
| Width | 434 mm |
|---|---|
| Height | 634 mm |
| Depth | 637 mm |
| Weight | 36.4 kg |
