With the MAUI 11 G3 SUB W subwoofer, you extend the cardioid characteristics of our professional column speaker series right into the bass range.
What does this mean?Simply position the SUB next to your MAUI® 11 G3 W facing the rear direction, switch on the Cardioid preset and you will have a quieter and controlled Low-End on the back while still keeping the punch on the front. Low-End frequencies on the back of the system will be dampened by -15 dB. For extra Bass, keep the SUB in the same direction as your MAUI® 11 G3 W and switch off the Cardioid preset.
Setting up the SUB with your MAUI® 11 G3 W is straight forward and fast. Thanks to its automatic set-up detection system the SUB immediately switches to FOLLOWER mode as long as no column is attached.
Also recommendable is the protection cover and castor board to make transportation easy and keep the SUB as long as possible free of any touring-damage.
The MAUI® 11 G3 SUB W features the same design construction as the MAUI® 11 G3 W subwoofer and will be the perfect addition to get your Low-End in control.
- Powered 2 x 8" subwoofer with flow-optimised bass-reflex ports
- 2 x 8" custom-designed woofer with deep bass down to 39 Hz
- Preset for cardioid subwoofer configuration
- DynX® DSP (Gen. 2) technology for distortion-free sound at maximum volume
- Automatic Setup Detection (MAIN / FOLLOWER)
- Rugged subwoofer housing made out of polyurea-coated birch plywood
- Shockproof front grille for ultimate speaker protection
- Two ergonomic handles for easy handling
General
| Peak output power | 1460 W |
|---|---|
| RMS output power | 730 W |
| Amp class | Class D |
| SysLink® | 1 |
| Max. SPL peak | 125 dB |
| Frequency response (-10 dB, rel. Avg) | 39 Hz |
| Number of inputs | 2 |
| Input connector types | XLR combo socket |
| Number of outputs | 3 |
| Output connector types | XLR 3-pole male |
| Protection features | Direct current, Multiband Limiter, Overheating, Short circuit |
| Colour | White |
Bluetooth®
| Bluetooth® version | 4.2 |
|---|---|
| Features | Audio Streaming (A2DP), True Wireless Stereo, App control |
| Supported audio codecs | AAC, SBC |
| Receiver (client) | 0 |
| Transmitter (host) | 0 |
Outputs
| Number of speaker outputs | 1 |
|---|---|
| Speaker output connection type | XLR 3-pole male |
Signal processing
| Mixer | 0 |
|---|
Amplifier
| Number of satellite outputs | 1 |
|---|
Bass driver
| Size | 8 " |
|---|---|
| Quantity | 2 |
| Manufacturer | Custom Made |
| Magnet | Ferrite |
| Voice coil | 2 " |
Mains operation
| Operation voltage | 110 V AC - 120 V AC / 50 - 60 Hz, 220 V AC - 240 V AC / 50 - 60 Hz |
|---|---|
| Power supply type | Switched-mode power supply (SMPS) |
| Mains connector | Mains socket indoor power in male & powerCON® |
| Mains fuse | T3.15AL/250 V |
Housing
| Design | Bass reflex |
|---|---|
| Number of handles | 1 |
| Cabinet material | Birch multiplex |
| Material thickness | 15 mm |
| Front grille material | Aluminium |
Cooling
| Cooling system | Convection cooling |
|---|
Environmental
| Ambient temperature | 0 °C |
|---|---|
| Maximum air humidity (non-condensing) | 80 % |
Dimensions & weight
| Width | 305 mm |
|---|---|
| Height | 607 mm |
| Depth | 403 mm |
| Weight | 20.5 kg |
Other properties
| Included accessories | Mains cable |
|---|
