WATCHOUT 7 – Next-Generation Multi-Display Production Software
WATCHOUT 7 is the complete reimagining of Dataton's industry-leading multi-display software. A powerful, fully scalable platform for composing and controlling spectacular shows across unlimited displays with pixel-perfect synchronization. From broadcast studios and live events to projection mapping, museums, and experience centers—WATCHOUT 7 is the choice of AV professionals worldwide.
Complete Ecosystem Architecture
WATCHOUT 7 introduces a modular architecture with four integrated components:
- Producer: Main creative interface where you design and edit shows
- Director: The brain—manages show data and synchronization
- Runner: Audio and video rendering engine
- Asset Manager: Centralized media repository with multi-user collaboration
Each component can run on separate computers or combined on a single machine for maximum flexibility.
Advanced Video Engine
- Up to 16-bit color depth
- HDR (High Dynamic Range) support
- Wide color space support (REC.2020+)
- Uncompressed playback at 4K resolution up to 120Hz
- Advanced codecs: H.265, NotchLC, Apple ProRes, HAP
- Full bi-directional NDI support
- Enhanced sync across multiple servers
Unlimited Scalability
- No limits on number of display devices
- No limits on resolution (4K, 8K, 16K+)
- Any aspect ratio, any arrangement
- Soft-edge blending and display masking
- Virtual displays for flexible pixel mapping
Professional Audio Engine
- Dante-ready networking
- ASIO/WASAPI support
- Audio bus routing with flexible output control
- Multiple audio devices per server
- Synchronized multi-channel playback
Advanced Synchronization
- NTP-based time-sync (less than 2ms delay on local networks)
- Wireless network support (WiFi, 3G, 4G, 5G)
- LTC (Linear Timecode) input support
- Multiple timeline synchronization across servers
Projection Mapping & 3D
- 3D model support and auto-alignment
- Marker-based calibration workflow
- Three stage view modes for precision mapping
- Virtual projector placement
- Content mapping to facades, objects, and complex surfaces
Media Capture & Live Integration
- Multiple low-latency capture cards
- USB capture support
- VNC capture
- NDI live streaming input/output
- Network-based workflows
Ideal for:
Broadcast studios, live events, projection mapping installations, theaters, museums, show rooms, visitor attractions, cruise ships, houses of worship, experience centers, corporate presentations, and any application requiring professional multi-display control with creative flexibility.
System Requirements:
Windows-based Producer and media server computers. Network connectivity required for multi-node deployments.
Licensing Model:
- Producer software: Free to download
- Media servers: Require WATCHOUT 7 license (built-in to WATCHPAX media servers)
- Flexible single or multi-server licensing
- Educational licenses available at discounted rates
