Product Description
| Lens type | Zoom Lens |
|---|---|
| F-number | 1.9–2.3 |
| Focal length (f) | 9.9–12.3 mm (25/64"–31/64") |
| Screen size | 70–1000 inches |
| Throw ratio → WUXGA | 0.550–0.690:1 |
| Auto Lens Identification function Compatible models |
PT-REQ15/REQ12/REQ10/REQ80/ PT-REZ15/REZ12/REZ10/REZ80 |
| Lens-shift → Vertical | ±50 % |
| Lens-shift → Horizontal | ±23 % |
| Zoom | x1.25 |
| Dimensions (W) | Approx. 154 mm (6 1/16") |
| Dimensions (H) | Approx. 155 mm (6 3/32") |
| Dimensions (D) | Approx. 245 mm (9 21/32") |
| Weight | Approx. 2.6 kg (5.7 lbs) |
| Applicable projectors | PT-REQ15/REQ12/REQ10/REQ80/ PT-REZ15/REZ12/REZ10/REZ80 |
| Dimensions (WxHxD) | 154 × 155 × 245 mm (6-1/16 × 6-3/32 × 9-21/32") |
