Product Description
Characteristics
Impedance: 4Ω
Frequency range: 120 Hz to 20,000 Hz
System: Line emitter
Wideband: 4
Nominal load capacity: 40 watt
Music load capacity: 80 watt
Radiation behavior
Beam angle horizontal: 1600°
Beam angle vertical: 40°
Characteristic sound pressure: 88 dB/W/m
Max. Nominal sound pressure: 106 dB
Housing
Material: Aluminum
Color: Black, white, silver, gold, (special colors on request)
Number of speakers: 4
Mounting: Screw-on bracket, metal (standard). (In-wall housing optional)
Zul. Temperature: 0°- 100° C
Wide: 37.5 mm
Height: 1206 mm
Depth: 23 mm
