Features
- Digital transmission over long distances due to DMX- and AES/EBU-Standards
- Very good protection against electrical interference (copper braiding + AL/PT-foil)
- Extremely robust due to the special tough jacket
Technical Data
| Jacket, diameter | PVC 7.0 mm |
| AWG | 22 |
| No. of inner conductors | 4 x 0.34 mm² |
| Copper strand per conductor | 7 x 0.25 mm |
| Conductor insulation | PE 1.70 mm |
| Shielding | Tin plated copper braided shielding with 128 x 0.10 mm+ AL/PT-foil |
| Shielding factor | 100 % |
| Temperature range | Min. -20 °C |
| Temperature range | Max. +70 °C |
| Packaging | 100/300 m roll |
Electrical Data
| Capac. cond./cond. per 1 m | 49.7 pF |
| Capac. cond./shield. per 1 m | 108.7 pF |
| Cond. resistance per 1 m | 52.9 mΩ |
| Shield. resistance per 1 m | 22.59 mΩ |
