Prolights ECLFSBK

كشّاف بروفايل LED، 91x3W RGBL LED، بصريات اختيارية، 4 شفرات، IP20، 220W، 7,3 kg، أسود

بالعرض فقط

السعر عند الطلب

إضافة إلى قائمة الأمنيات

عرض على موقع الشركة المصنّعة

رمز المنتج: ECLFSBK

الفئة: كشّاف بروفايل

العلامة التجارية: Prolights

التوصيل للطلبات التي تتجاوز 1,000 درهم

الضمان 2 سنوات

دفع آمن معاملات مشفرة وآمنة

دعم متخصص دعم ما قبل وما بعد البيع

استشر خبيراً

فريقنا جاهز لمساعدتك.

استشر خبيراً

فريقنا جاهز لمساعدتك.

اتصل بنا

تحتاج عرض سعر؟

سنوفر لك تسعيرة مخصصة لمشروعك.

طلب عرض سعر

EclProfile FS is a full colour elipsoidal LED, designed to deliver a full range of pastels, saturates and whites, both with or without gobos. The EclProfile FS' RGB + Lime LED engine has been specially engineered to provide a full spectrum and full output in the most discerning environments, regardless of which role the EclProfile FS is playing.

RGB + Lime ellipsoidal LED with HD dimming and extensive colour palette

High definition optics for sharp focus and gobo projection

Accepts industry standard accessories

Features:
RGB + Lime ellipsoidal LED with HD dimming and extensive colour palette
High definition optics for sharp focus and gobo projection
Accepts industry standard accessories

LIGHT SOURCE

Source:

91x3
W

RGB + Lime LEDs
Source CCT:

@full 5.000
K
Luminous flux:

(5°) TBD; (10°) TBD; (14°) 4'619 lm; (19°) 5'133 lm; (26°) 6'100 lm; (36°) 5'970 lm; (50°) 5'596 lm; (70°) TBD

@Full
Lux:

(5°) TBD; (10°) TBD; (14°) 4'321 lx; (19°) 2'567 lx; (26°) 1'711 lx; (36°) 873 lx; (50°) 462 lx; (70°) TBD
lx

@5 m full
CRI:

86 @3.200 K; 85 @5.600 K
TLCI:

82 @5.600 K
TM30 Rf:

84 @3.200 K
TM30 Rg:

109 @3.200 K
Source life expectancy:

> 50.000 h

OPTICS

Lens type:

high-quality glass lens optics
Additional optics:

optional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / zoom 15°-30° / zoom 25°-50
Focus:

manual

COLOUR SYSTEM

Colour mixing:

RGB + lime / full colour
CCT:

CCT control through dedicated DMX channel
White presets:

2.700 K ~ 10.000
K
Colour wheel:

virtual colour wheel with macros

DYNAMIC EFFECTS

Static mode:

selection of static colour
Manual mode:

manual adjustment of colour
Auto mode:

built-in programs with execution speed adjustment
Special features:

different presets for fan mode and output management
Other:

automatic software colour balance when fixture warms up - linear crossfade from a white to any color and virtual CTO app

GOBOS

Gobo size:

(B size) 86 mm outer / 64.5 mm image / 1.1 mm thickness

CONTROL

Supported Protocols:

DMX512, RDM
DMX channels:

1 / 2 / 3RGB / 4RGBL / 5RGBL / 3 / 4 / 5 / 8 / 13 ch - Tungsten / 3.200 K / 5.400 K / 6.500 K
ch
RDM:

for remote addressing and parameter configuration
Display:

Graphic User Interface
Master/Slave:

for synchronised operation of more units linked in a chain
