Martin Audio FP15

The FP15 is a premium, point-source loudspeaker designed for short and medium-throw applications which require superb sonic performance, very high output, and low frequency extension from a standalone enclosure.

Features

• Versatile, premium two-way loudspeaker system
• Multi-angle enclosure with very high output capability
• Coaxial Point Source configuration with user-rotatable drive unit
• 15” (380mm)/3.5” (89mm) voice coil low distortion neodymium LF driver
• 3” (75mm) titanium diaphragm/1.4” (35mm) exit HF driver
• 80° H x 50° V dispersion
• Quick-release steel grille
• 3D prediction software [DISPLAY 3]
• Powered by iKON or VIA amplifiers

With a multi-angle enclosure and a wide range of mounting options, the FP15 is the perfect high-power solution for rental companies and applications which benefit from its flexibility and speed of deployment. When supplemented by a subwoofer, it is an excellent choice for a top-flight portable live sound reinforcement system for bands and DJs. It can also be used as a powerful stage monitor, or in conjunction with a larger touring or installed sound system.

The FP15 is a two-way passive loudspeaker featuring a high-specification 15” LF driver and a 1.4” exit HF driver with a 3” diameter titanium diaphragm. It effortlessly delivers an impressive maximum SPL of 132dB peak and has a well-defined dispersion pattern of 80° horizontal x 50° vertical, with constant horizontal directivity characteristics.

Its exemplary coverage pattern is achieved by incorporating a dedicated waveguide within the magnet structure which merges into a specially contoured LF cone. With the waveguide and cone combining to form the HF horn, this innovative arrangement avoids a separate ‘add-on’ horn which would impede the wavefront from the cone and cause irregularities in the frequency response. It also improves on conventional through-the-pole coaxial designs, which can suffer from high frequency beaming
